196 Section 2 Nonstructural Repairs
ASE-Type Questions
1 1. T T echnician ec hn ic ia n A A says sa ys t t hat ha t a a lateral la te ra l force fo rc e acting ac ti ng
on a h h igh ig h- crown panel p l causes arrowh he ds. ad
Technician Te ch ni ci an B B s s ays ay s that th at a a n n upset up se t is is a a n n increase in cr ea se i i n n
the th su face rf area of f a panel p l. W W h ho i i s ight? ri gh t?
(A) (A ) A A only. on ly
(B) (B ) B B onl ly .
(C) Both A and B.
(D) Neither A nor B.
2. A damaged vehicle is being analyzed by two
technicians. Technician A says that any damaged
internal braces must be identified. Technician B
says that any change in surface area must be
identified. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
3. Planning includes which of the following?
(A) Deciding what tools are needed.
(B) Determining how to access the back side of a
panel.
(C) Identifying obstructions.
(D) All of the above.
4. Plastic fender liners are held in place by which of
the following?
(A) Plastic rivets.
(B) Bolts.
(C) Welds.
(D) Both A and B.
5. Technician A says a longitudinal force can shorten
a panel’s overall length. Technician B says a lateral
force can also shorten a panel. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
6. Pushing with a 4-ton body jack provides what type
of corrective force?
(A) Shock.
(B) Longitudinal.
(C) Tension.
(D) Lateral.
7. When stretching upset metal, Technician A says
that the dolly should match the shape of the
undamaged panel. Technician B says that the
upset area is hit hammer-off-dolly. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
8. False stretch is corrected by .
(A) shrinking
(B) tapping on the nearest body line
(C) removing an adjacent upset
(D) All of the above.
9. Leveling is used to .
(A) raise high areas, lower low areas
(B) raise low areas, lower high areas
(C) stretch metal
(D) shrink metal
10. A low spot is raised with a draw pin. Technician A
says the raised spot will be work hardened.
Technician B says the raised spot will be softer
than the surrounding metal. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
11. A damaged body line can be raised with a .
(A) gang clamp and draw pins
(B) body chisel
(C) body jack and angle iron
(D) All of the above.
12. All of the following can be used to shrink metal
except a(n) .
(A) draw pin welder
(B) oxyacetylene torch
(C) shrinking hammer
(D) pull plate
13. Shrinking stretched metal with an oxyacetylene
torch requires what size of tip?
(A) #1.
(B) #3.
(C) #5.
(D) #7.
14. When heat shrinking, the metal should be heated
to what color?
(A) White.
(B) Orange.
(C) Red.
(D) Yellow.
15. A low area is to be filled. Technician A says the low
area should be ground to the bare metal before filler
is applied. Technician B says the low area should be
ground to bare metal and then sprayed with epoxy
primer before filler is applied. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
