The paper wrapping is removed to expose the insulation
covering the wire conductor. Carefully strip off the insulation using
the multipurpose stripping tool shown in Figure 7-8, or a BX cutter.
See Figure 10-3B.
Cutting armored cable with metal-cutting shears is shown in
Figure 10-4. First, bend the armor sharply to buckle it. Then, grip the
cable on both sides of the buckled point and twist against the
direction of the spiral to open one turn of cable winding. Cut with
snips and trim off sharp corners. Removing armor exposes water-
repellent paper wrapping.
Unit 10 Basic Wiring Systems 69
Figure 10-3. A. Using hacksaw to cut armored cable. B. Using notch on BX
cutter to strip insulation.
A
B
Figure 10-4. Cutting cable with metal-cutting shears.
