Chapter 10 Dimensioning
285
30.
Design Problems
Design and prepare drawings for the following.
A. Storage cabinet for video games
B. Carrying case for gaming accessories
C. Wall hanger for skateboard or snowboard
D. Portable storage case for DVDs
E. Snowboard or sled
F. Ice skating blade
G. Snooker or pool equipment rack
Problem 10-30. Design Problems. Complete each design problem. Draw and dimension as many views
as necessary to fully describe the object.
