SNAP RING QUIZ
Refer to Fig. 4-25. Study the drawing and familiarize yourself with the views, dimensions, title block, and
notes. Read the quiz questions, refer to the print, and write your answers in the blanks provided.
1. What is the part number?
2. Name the type of material used to make the
part.
3. State what change was made by revision D.
4. What is the scale of the drawing?
5. Who released revision A for production?
6. What size is the drawing?
7. Who created the drawing?
8. What is the ring thickness?
9. What is the required width of the blue paint
stripe?
10. What tolerance is specified for angles?
11. Who was responsible for making revision B?
12. What is the name of the part?
13. Dimensions .280, 3.835, .134, and .334 are
examples of what type of limits?
14. What tolerance is used for one-place decimal
dimensions?
15. What is the maximum value for unspecified
surface finishes?
16. What is the minimum allowable size on the
.136 dimension?
17. What is the tolerance for the FREE DIA?
18. What is the tolerance for the ring thickness?
19. Ring should be made from what existing part?
20. What is the tolerance for the ring width
opposite the gap?
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
