COLOR KEY
A color key is used throughout Modern
Metalworking to indicate various materials or
equipment features. The following key shows
what each color represents.
IMPORTANT SAFETY NOTICE
Work procedures and shop practices
described in this book are effective, but general,
methods of performing given operations. Use
special tools and equipment as recommended.
Carefully follow all safety warnings and cautions
(they are printed in red type). Note that these warn-
ings are not exhaustive. Proceed with care and
under proper supervision to minimize the risk of
personal injury or injury to others. Safety equip-
ment may have been removed or opened on
some illustrations to clearly show a machine
function and must be in place before operation.
This book contains the most complete and
accurate information that could be obtained from
various authoritative sources at the time of publi-
cation. The Goodheart-Willcox Co., Inc. cannot
assume responsibility for any changes, errors, or
omissions.
ABOUT THE AUTHOR
John Walker is the author of thirteen text-
books and has written many magazine articles.
Mr. Walker did his undergraduate studies at
Millersville University and has an MS in
Industrial Education from the University of
Maryland. He taught industrial arts and voca-
tional education for thirty-two years and was
Supervisor of Industrial Education for five years.
The author also worked as a machinist for the US
Air Force and as a draftsman at the US Army
Aberdeen Proving Grounds.
4 Modern Metalworking
Metals (surfaces)
Metals (in section)
Machines/machine parts
Tools
Cutting edges
Work-holding and tool-holding devices
Rulers and measuring devices
Direction or force arrows,
dimensional information
Fasteners
Abrasives
Fluids
Miscellaneous
