It is important the lathe be covered during
grinding operations to protect it from the
resulting abrasive dust and grit, Figure 28-24.
Cover the lathe bed, cross-slide, and other parts
with canvas or heavy kraft paper.
28.7 MILLING
Many small shops are not equipped with a
milling machine. Therefore, lathe manufacturers
have devised attachments that permit milling oper-
ations to be performed on the lathe, Figure 28-25.
The milling cutters are mounted on an arbor
or fitted to the headstock spindle. The cut is
controlled by carriage and cross-slide movements.
456 Modern Metalworking
Metal to
be turned
Mandrel
Figure 28-21.
A lathe mandrel with work mounted for turning.
Figure 28-22.
Hand-operated arbor press. It is made in many sizes.
(Dake Corp.)
Figure 28-23.
Tool post grinder finishing shaft mounted between
centers. (Clausing Industrial, Inc.)
Figure 28-24.
Tool post grinders. A—Light-duty tool post grinder.
(The Dumore Co.) B—Reciprocating type tool post
grinder. (NSK America)
B
A
