Refer to the print PR 11-1 and answer the questions below.
Industry Print Exercise 11-1
1. How many counterbored holes does this part have? ______________________________________________________
2. How many countersunk holes does this part have? _______________________________________________________
3. Does this drawing feature symbols dictated by current standards for local note callouts? _____________
4. What process will be used to put the part number on the part? __________________________________________
5. What machining process will be used to eliminate sharp corners? _______________________________________
6. What machining process is specified for the slot? _________________________________________________________
Review questions based on previous units:
7. How many leader lines are there on this print? ____________________________________________________________
8. If the view with the cutting-plane line is the front view, what is the width of the object? ______________
9. How many threaded holes does this part have? ___________________________________________________________
10. Of the threads that feature a major diameter of 5/8†, what is the pitch? _________________________________
11. What type of section view is the right side view? _________________________________________________________
12. What is the name of this part? ______________________________________________________________________________
13. What size paper was the original drawing for this print? _________________________________________________
14. Is the left side of this part symmetrical with the right side? ______________________________________________
15. What scale was used for the views on the original drawing for this print? ______________________________
