384 Automatic Transmissions and Transaxles
4. Technician A says that some shift cables can be dam-
aged if the engine ground straps are disconnected.
Technician B says that the throttle valve linkage on
vehicles without modulators is used only for passing
gear. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
5. Technician A says that the band adjustment screw
must be tightened against the drum and then backed
off a certain number of turns to properly adjust the
band. Technician B says that backing off the band
adjustment screw less than specified will generally
provide a firmer shift. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
6. Replacement parts are being ordered for an auto matic
transaxle. Technician A says that needed parts should
be identified and ordered as soon as possible to
reduce waiting time. Technician B says that the new
parts should be compared to the old parts to ensure
that they are correct. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
7. To drain a transmission pan that does not have a drain
plug, the technician should remove all pan bolts
except:
(A) those at each corner.
(B) the rear four.
(C) the front four.
(D) two on each side.
8. A case-mounted governor should be checked for all
the following except:
(A) a stripped gear.
(B) missing springs.
(C) leaking diaphragm.
(D) a stuck valve.
9. Technician A says that a vacuum modulator, when
used, should have a leak-free connection to the intake
manifold. Technician B says that transmission fluid on
the vacuum hose side of the modulator is a normal
condition. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
10. Technician A says that all valves should be checked
for free movement in the valve body. Technician B
says that valves should be removed and reinstalled
one at a time to reduce the possibility of mixing up
valves or springs. Who is right?
(A) A only.
(B) B only.
(C) Both A and B.
(D) Neither A nor B.
