Print AP-020:
24. Which one of the following processes does not apply to this part?
A. Forging.
B. Carburizing.
C. Grinding.
D. Welding.
25. What term is applied to breaking off the sharp edges of the teeth? ______________________________________
___________________________________________________________________________________________________
Print AP-021:
26. Which of the general notes specifies a geometric control and, thus, could be replaced with a feature
control frame? ________________________________________________________________________________________________
___________________________________________________________________________________________________
Print AP-022:
27. What is the basic radius for fillets and rounds, unless otherwise specified? _____________________________
___________________________________________________________________________________________________
28. How many leader lines are used in this print for notes? __________________________________________________
___________________________________________________________________________________________________
Print AP-023:
29. What finish is specified for this part? _______________________________________________________________________
___________________________________________________________________________________________________
30. How are burrs to be removed? ______________________________________________________________________________
___________________________________________________________________________________________________
Print AP-025:
31. Unless specified, what imperfection along the edges is acceptable? _____________________________________
___________________________________________________________________________________________________
Print AP-026:
32. What do the circular hidden lines represent in the top view? ____________________________________________
___________________________________________________________________________________________________
