94 Print Reading for Industry
1. Not counting the removed view and pictorial views, how many regular views does this
object have? __________________________________________________________________________________________________
2. How many of the regular views feature height? ___________________________________________________________
3. If the view that is closest to the center of the sheet is the front view, what is the name of the view
directly below it? _____________________________________________________________________________________________
4. The flat surface that shows true size and shape in the top view is parallel to the _______________________
plane of projection.
5. In which view is the viewing-plane line shown for the removed view? _________________________________
6. What two dimensions (names) are featured in the left side view? _______________________________________
7. Does this object appear to have any inclined surfaces? ___________________________________________________
8. Which dimension is greater, width or depth? ______________________________________________________________
9. What is the name of the removed view? ___________________________________________________________________
10. Are hidden lines shown in the top view? __________________________________________________________________
Review questions based on previous units:
11. Which view features cutting-plane lines? __________________________________________________________________
12. What is the drawing number or part number? ____________________________________________________________
13. How many views feature section lines? ____________________________________________________________________
14. What is the most recent date associated with this drawing? ______________________________________________
15. The annotation on the left side view features a couple of ___________________________________________ lines.
Refer to the print PR 5-2 and answer the questions below.
Industry Print Exercise 5-2
