AutoCAD includes many editing n n commands and options to complete common
drafting tasks, improve efficiency, and modify a drawing. This chapter explains
methods of using basic editing commands for changing or adding geometry to
existing objects. The editing method used in this chapter is to access a command such
as STRETCH and then follow the prompts to complete the operation. Another tech-
nique, presented in Chapter 13, is to select objects first using the crosshairs, then access
the editing command, and finally complete the operation.
Using the FILLET Command Using the FILLET Command
Design and drafting terminology refers to a rounded interior corner as a fillet, fi t
and a rounded exterior corner as a round. AutoCAD refers to all rounded corners as
fillets. The FILLET command draws a rounded corner between intersecting or nonin-
tersecting lines, circles, arcs, polylines, and splines. See Figure 11-1.
Setting the Fillet Ra adius
Access the FILLET command and then use the Radius option to specify the fillet
The radius determines the size of a f fillet and must be set before you select
AutoCAD stores the radius as the new default radius, allowing you to place
fillets of the f same size.. After you define the radius, select the first object and
hover the pick box over the second object to display a preview of the f operation.
FILLET
Ribbon
Home
Modify
Fillet
Type
FILLET
F
fillet: A rounded
interior corner used
to relieve stress or
ease the contour of
inside corners.
round: A rounded
exterior corner used
to remove sharp
edges or ease the
contour of exterior
corners.
