Chapter 10 Dimensioning
277
STEM Activities
1. Engineering: Go to the school library.
Find a shelf of books that are written
on a topic that interests you. Measure
the height, width, and thickness of
each book and calculate the volume
in cubic inches. Design a three-shelf
bookcase large enough to hold just these
books with no room to spare. Create a
multiview drawing of the bookcase. Fully
dimension the drawing using the rules of
dimensioning discussed in this chapter.
Take care to create the drawing and
dimensions with the proper line weights.
2. Engineering: Measure all of your
CDs and DVDs. Calculate how much
space they require. Design a carrying
case for the CDs and DVDs. Create a
multiview drawing of your design. Fully
dimension the drawing using the rules of
dimensioning discussed in this chapter.
Communicating about
Drafting
Working with a partner, create a
multiview drawing of your textbook. Use
the information in this textbook and do any
research needed to dimension your drawing.
Share your drawing with the class. Discuss
the importance of accurate dimensions.
Drawing Problems
Draw the problems shown on the following
pages. Follow the directions in each problem.
Check Your Drafting IQ
Now that you have finished this chapter, see what you learned
by taking the chapter posttest.
www.g-wlearning.com/drafting/
Copyright Goodheart-Willcox Co., Inc.
