88 Print Reading for Industry
Review Activity 5-4
True Size and Shape Identification
Analyze each of the multiview drawings.
Place a T for true size and shape or an F for
foreshortened size and shape in the blanks below each
multiview. Remember, normal surfaces appear true
size and shape in only one view. Inclined surfaces
appear foreshortened in shape and size in two views.
The first problem is done for you as an example.
